The third-generation Intel® Xeon scalable processor is adopted, with up to 80 processing cores and 160 threads, and the processor is also integrated with Intel® OPA100Gb high-speed computing network chip; it supports the upgrade of the BBP backup battery module, which can be realized under sudden power failure Data protection, providing a more secure and effective solution for mission-critical servers, a dual-socket rack server designed for complex software applications
Application Scenarios: Cloud Computing, Desktop Cloud, High Performance Computing, Database Processing and Storage, Storage High Availability, Hosting and Application Delivery
Intel® new Xeon series architecture, a single processor with up to 80 cores and 160 threads, the channel between the two processors uses a new UPI interconnection link, and the frequency is as high as 11.2GT/s. The memory channel is upgraded to 6, the maximum frequency is 3200MHz, and the maximum memory capacity is increased by 50% compared with the previous generation; the new generation of Intel® C621A series chipset has more powerful expansion performance, and can expand multiple SATA3.0, USB3.0, High-speed interfaces such as M.2 and NVMe.
Supports up to 24 SATA/SAS/SSD (optional) hot-swappable hard drives, optional built-in two 2.5-inch SSD system disks and two M.2 PCI-E SSDs; memory capacity can support up to 2TB, with advanced memory fault tolerance Function; onboard 2 gigabit data network ports, with load balancing, fault recovery and sideband support features, which can effectively reduce network delay; optional support for 1+1 safe redundant power supply mode, providing more security for server operation High security.
The new generation of Purely series processors supports the new technologies of Intel® VMD and VROC, comprehensively manages NVMeSSD, supports RAID0, 1, and 5 functions, and provides a highly reliable solution for all NVMeSSD data centers with high IO and low latency, truly ushering in NVMeSSD big data era. The Intel® AVX instruction set has been upgraded to AVX3.0 again. The 512-bit bit width is twice that of the previous generation Intel® AVX2.0, which significantly accelerates the speed of vector and floating-point operations, bringing more powerful performance to high-performance computing applications.
| CPU | Intel® C621A Chipset |
| Chip Group | UPI up to 11.2 GT/s |
| System Bus | Standard 8 DIMM slots, support 3200/2933/2666 MHz ECC LRDIMM/RDIMM memory, maximum support 2TB |
| Storage | memory |
| Hard Drives | 24 hot-swappable 3.5” or 2.5” SATA/SAS/SSD (optional) data disks, optional built-in 2 2.5” SSD system disks and 2 M.2 PCI-E SSDs |
| integrated chip | Standard 4* PCI-E 4.0 x16, 2* PCI-E 4.0 M.2 22110/2280 slot 1*VGA interface, 2*USB3.2 (rear) |
| Expander Slots | 1. Integrated display chip 2. Integrated 1 1000Base-T management network port 3. Integrated 2 Gigabit network ports 4. Integrated RAID 0, 1, 5, 10 functions (Only for Windows), optional hard RAID function |
| Peripheral interface | 2*USB2.0(Front ) 、2*RJ45 Internet interface、1*Dedicated remote management port |
